2017 Mercedes-Benz Sprinter Specs, Features & Options
Here's everything you need to know about each trim in the 2017 Mercedes-Benz Sprinter lineup. Compare pricing, specs, key features and more.
1 of 18  Sprinter 3500 XD Cargo High Roof w/144" WB Van 3D | 2 of 18  Sprinter 3500 Cargo High Roof w/144" WB Van 3D | 3 of 18  Sprinter 2500 Cargo Standard Roof w/144" WB Van 3D | 4 of 18  Sprinter 2500 Crew Standard Roof w/144" WB Van 3D | 5 of 18  Sprinter 2500 Passenger Standard Roof w/144" WB Van 3D | 6 of 18 Sprinter 2500 Cargo High Roof w/144" WB Van 3D | 7 of 18  Sprinter 2500 Cargo High Roof w/170" WB Van 3D | 8 of 18  Sprinter 2500 Crew High Roof w/170" WB Van 3D | 9 of 18  Sprinter 2500 Passenger High Roof w/170" WB Van 3D | 10 of 18  Sprinter 3500 Cargo Standard Roof w/144" WB Van 3D | 11 of 18 Sprinter 2500 Passenger High Roof w/144" WB Van 3D | 12 of 18  Sprinter 3500 XD Cargo High Roof w/170" WB Van 3D | 13 of 18 Sprinter 2500 Cargo High Roof Extended w/170" WB Van 3D | 14 of 18 Sprinter 2500 Crew High Roof w/144" WB Van 3D | 15 of 18  Sprinter 3500 XD Cargo Standard Roof w/144" WB Van 3D | 16 of 18 Sprinter 3500 Cargo High Roof w/170" WB Van 3D | 17 of 18 Sprinter 3500 Cargo High Roof Extended w/170" WB Van 3D | 18 of 18 Sprinter 3500 XD Cargo High Roof Extended w/170" WB Van 3D | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Fair Market Price | $25,464 | $25,489 | $27,517 | $27,968 | $28,533 | $30,291 | $30,616 | $32,337 | $33,272 | $33,299 | $33,514 | $33,884 | $34,677 | $34,881 | $35,881 | $36,574 | $36,947 | $37,574 | ||
| Fuel Type | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | ||
| Horsepower | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | N/A | N/A | 188 @ 3800 RPM | 188 @ 3800 RPM | N/A | N/A | 188 @ 3800 RPM | N/A | 188 @ 3800 RPM | 188 @ 3800 RPM | N/A | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | ||
| Seating | N/A | N/A | 3 | 5 | 12 | N/A | 3 | 5 | 12 | 3 | N/A | 3 | 3 | N/A | 3 | 3 | 3 | 3 | ||
| Cargo Volume | 329.30 cu ft | 359.40 cu ft | 319.10 cu ft | 220.10 cu ft | 68.60 cu ft | 319.10 cu ft | 486.50 cu ft | 367.50 cu ft | 190.30 cu ft | 359.40 cu ft | 68.60 cu ft | 428.70 cu ft | 530.00 cu ft | 220.10 cu ft | 329.30 cu ft | 467.80 cu ft | 509.70 cu ft | 467.00 cu ft | ||
| Tire Size | LT215/85R16 | P205/65R16 | LT245/75R16 | LT245/75R16 | LT245/75R16 | LT245/75R16 | LT245/75R16 | LT245/75R16 | LT245/75R16 | P205/65R16 | LT245/75R16 | LT215/85R16 | LT245/75R16 | LT245/75R16 | LT215/85R16 | P205/65R16 | P205/65R16 | LT215/85R16 | ||
| Towing Capacity | 7,500 lbs | 7,500 lbs | 5,000 lbs | 5,000 lbs | 5,000 lbs | 5,000 lbs | 5,000 lbs | 5,000 lbs | 5,000 lbs | 7,500 lbs | 5,000 lbs | 7,500 lbs | 5,000 lbs | 5,000 lbs | 7,500 lbs | 7,500 lbs | 5,000 lbs | 5,000 lbs | ||
| Transmission | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | ||
| Curb Weight | N/A | N/A | 5,038 pounds | 5,324 pounds | 5,655 pounds | 5,038 pounds | 5,434 pounds | 5,765 pounds | 6,239 pounds | N/A | 5,655 pounds | N/A | 5,556 pounds | 5,324 pounds | N/A | N/A | N/A | N/A | ||
| Dimensions | 233.3" L x 95.5" W x 107" H | 233.3" L x 95.5" W x 107.3" H | 233.3" L x 95.5" W x 94.5" H | 233.3" L x 95.5" W x 94.3" H | 233.3" L x 95.5" W x 100.6" H | 233.3" L x 95.5" W x 105.7" H | 274.1" L x 95.5" W x 105.8" H | 274.1" L x 95.5" W x 105.5" H | 274.1" L x 95.5" W x 110" H | 233.3" L x 95.5" W x 107.5" H | 233.3" L x 95.5" W x 110" H | 274.1" L x 95.5" W x 107" H | 289.8" L x 95.5" W x 105.7" H | 233.3" L x 95.5" W x 105.5" H | 233.3" L x 95.5" W x 107.3" H | 274.1" L x 95.5" W x 107.3" H | 289.8" L x 95.5" W x 107.2" H | 289.8" L x 95.5" W x 106.1" H |
| Blind-Spot Alert | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Child Seat Anchors | Not available | Not available | Not available | Standard | Standard | Not available | Not available | Standard | Standard | Not available | Standard | Not available | Not available | Standard | Not available | Not available | Not available | Not available | ||
| Child Door Locks | Not available | Not available | Not available | Not available | Standard | Not available | Not available | Not available | Standard | Not available | Standard | Not available | Not available | Not available | Not available | Not available | Not available | Not available | ||
| Traction Control | Not Available | Not Available | Optional | Standard | Standard | Not Available | Optional | Standard | Standard | Not Available | Not Available | Not Available | Optional | Not Available | Not Available | Not Available | Not Available | Not Available |
| Bluetooth Wireless Technology | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Cruise Control | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Remote Keyless Entry | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Navigation System | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Hands Free Phone | Not Available | Not Available | Standard | Not Available | Standard | Not Available | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard |
| iPod Connector | Not Available | Not Available | Standard | Not Available | Not Available | Not Available | Standard | Not Available | Not Available | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| iPod Interface | Not Available | Not Available | Standard | Not Available | Not Available | Not Available | Standard | Not Available | Not Available | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Bluetooth Streaming Audio | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Bluetooth Wireless Technology | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard |
| Remote Keyless Entry | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Cruise Control | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Bluetooth Streaming Audio | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Heated Mirrors | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Heated Windshield | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional |
| Torque | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | Not Available | Not Available | 325 @ 3800 RPM | 325 @ 3800 RPM | Not Available | Not Available | 325 @ 3800 RPM | Not Available | 325 @ 3800 RPM | 325 @ 3800 RPM | Not Available | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM |
| Third Row Seat | Not Available | Not Available | Not Available | Not Available | Standard | Not Available | Not Available | Not Available | Standard | Not Available | Not Available | Not Available | Not Available | Not Available | Not Available | Not Available | Not Available | Not Available |
| Leather-Wrapped Steering Wheel | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Power Outlet | Not Available | Not Available | Optional | Standard | Standard | Not Available | Optional | Standard | Standard | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Power Windows | Not Available | Not Available | Not Available | Standard | Standard | Not Available | Not Available | Standard | Standard | Not Available | Not Available | Not Available | Not Available | Not Available | Not Available | Not Available | Not Available | Not Available | ||
| Rear Window Defroster | Not Available | Not Available | Optional | Standard | Standard | Not Available | Optional | Standard | Standard | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Tilt Steering Wheel | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Tilt/Telescoping Steering Wheel | Not Available | Not Available | Standard | Standard | Not Available | Not Available | Standard | Standard | Not Available | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Cup Holder Count | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard |
| Alloy Wheels | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Not Available | Not Available | Not Available | Optional | Not Available | Not Available | Not Available | Not Available | Not Available | ||
| Fog Lights | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Privacy Glass | Not Available | Not Available | Optional | Standard | Standard | Not Available | Optional | Standard | Standard | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Roof Rails | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Rain Sensing Windshield Wipers | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional |
| Alarm System | Not Available | Not Available | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Optional | Optional | Optional | Optional |
| Drivetrain | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | ||
| Hill Start Assist | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Recommended Fuel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | ||
| Stability Control | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Transmission Type | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic |
| Curb Weight | Not Available | Not Available | 5038 pounds | 5324 pounds | 5655 pounds | 5038 pounds | 5434 pounds | 5765 pounds | 6239 pounds | Not Available | 5655 pounds | Not Available | 5556 pounds | 5324 pounds | Not Available | Not Available | Not Available | Not Available | ||
| Fuel Capacity | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | ||
| Minimum Ground Clearance | 7.8 inches | 7.8 inches | 7.9 inches | 7.9 inches | 7.9 inches | 7.9 inches | 7.9 inches | 7.9 inches | 7.9 inches | 7.8 inches | 7.9 inches | 7.8 inches | 7.9 inches | 7.9 inches | 7.8 inches | 7.8 inches | 7.8 inches | 7.8 inches | ||
| Overall Length | 233.3 inches | 233.3 inches | 233.3 inches | 233.3 inches | 233.3 inches | 233.3 inches | 274.1 inches | 274.1 inches | 274.1 inches | 233.3 inches | 233.3 inches | 274.1 inches | 289.8 inches | 233.3 inches | 233.3 inches | 274.1 inches | 289.8 inches | 289.8 inches | ||
| Payload Capacity | 5507 pounds | 4456 pounds | 3512 pounds | 3226 pounds | 2752 pounds | 3512 pounds | 3116 pounds | 2785 pounds | 2311 pounds | 4456 pounds | 2752 pounds | 5133 pounds | 2994 pounds | 3226 pounds | 5507 pounds | 4170 pounds | 4004 pounds | 4967 pounds | ||
| Turning Diameter | Not Available | Not Available | 44.6 feet | 47.6 feet | 47.6 feet | Not Available | 51.5 feet | 54.8 feet | 54.8 feet | 44.6 feet | 47.6 feet | 51.5 feet | 51.5 feet | 47.6 feet | 44.6 feet | 51.5 feet | 51.5 feet | 51.5 feet | ||
| Wheel Base | 144.3 inches | 144.3 inches | 144.3 inches | 144.3 inches | 144.3 inches | 144.3 inches | 170.3 inches | 170.3 inches | 170.3 inches | 144.3 inches | 144.3 inches | 170.3 inches | 170.3 inches | 144.3 inches | 144.3 inches | 170.3 inches | 170.3 inches | 170.3 inches | ||
| Width with mirrors | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches |
FAQs
Is the Mercedes-Benz Sprinter a 4 or 6 cylinder?
All trim levels of the 2017 Sprinter feature a 6 cylinder engine. For a more detailed look at the 2017 Sprinter specs, features and options check out Kelley Blue Book's 2017 Mercedes-Benz Sprinter specs page.
Does the 2017 Mercedes-Benz Sprinter have a turbo?
Yes, the following 2017 Sprinter trims have turbo engines: High Roof w/144" WB Van 3D with a V6, Turbo Diesel, 3.0 Liter, High Roof w/144" WB Van 3D with a V6, Turbo Diesel, 3.0 Liter, etc. For a more detailed look at the 2017 Sprinter specs, features and options check out Kelley Blue Book's 2017 Mercedes-Benz Sprinter specs page.
All 2017 Mercedes-Benz Sprinter Trims and Styles
- 2017 Mercedes-Benz Sprinter 3500 XD Cargo High Roof W/144" WB Van 3D
- 2017 Mercedes-Benz Sprinter 3500 Cargo High Roof W/144" WB Van 3D
- 2017 Mercedes-Benz Sprinter 2500 Cargo Standard Roof W/144" WB Van 3D
- 2017 Mercedes-Benz Sprinter 2500 Crew Standard Roof W/144" WB Van 3D
- 2017 Mercedes-Benz Sprinter 2500 Passenger Standard Roof W/144" WB Van 3D
- 2017 Mercedes-Benz Sprinter 2500 Cargo High Roof W/144" WB Van 3D
- 2017 Mercedes-Benz Sprinter 2500 Cargo High Roof W/170" WB Van 3D
- 2017 Mercedes-Benz Sprinter 2500 Crew High Roof W/170" WB Van 3D
- 2017 Mercedes-Benz Sprinter 2500 Passenger High Roof W/170" WB Van 3D
- 2017 Mercedes-Benz Sprinter 3500 Cargo Standard Roof W/144" WB Van 3D
- 2017 Mercedes-Benz Sprinter 2500 Passenger High Roof W/144" WB Van 3D
- 2017 Mercedes-Benz Sprinter 3500 XD Cargo High Roof W/170" WB Van 3D
- 2017 Mercedes-Benz Sprinter 2500 Cargo High Roof Extended W/170" WB Van 3D
- 2017 Mercedes-Benz Sprinter 2500 Crew High Roof W/144" WB Van 3D
- 2017 Mercedes-Benz Sprinter 3500 XD Cargo Standard Roof W/144" WB Van 3D
- 2017 Mercedes-Benz Sprinter 3500 Cargo High Roof W/170" WB Van 3D
- 2017 Mercedes-Benz Sprinter 3500 Cargo High Roof Extended W/170" WB Van 3D
- 2017 Mercedes-Benz Sprinter 3500 XD Cargo High Roof Extended W/170" WB Van 3D
